1-2 Section 1: Introducing the Model 9500B
Final Width = 215mm
Descriptions assume 9500B/1100
• Composite Video Function:
Polarity: Positive and Negative sync
Patterns: Full Raster Selectable: White, Mid Grey or Black.
Amplitude Levels p-p: White: 1V, mid-grey: 0.7V, black: 0.3V. No deviation.
Frame Standards: 625 lines/50Hz, 525 lines/60Hz
Trigger: Calibrator trigger output selectable to Odd Field Start, or
Composite Sync.
• Linear Ramp Function:
Period: 3s, 300ms, 30ms, 3ms.
Ramps: Equal Rise, Fall and Flat divisions per cycle.
Amplitude: 1V pk-pk
Bias: Symmetrical about ground
Trigger Alignment: Start of rising or falling ramp
• Overload Pulse Function:
Pulse Amplitude: 5.0V to 20.0V (0.1V resolution)
Pulse Energy: 1.6J to 50.0J (0.1J resolution)
Polarity: Positive or negative from ground
Pulse Duration: at 20V: 200ms to 6.25s; at 5V: 3.2s to 100s
(Internally calculated from Amplitude and Energy)
Power into 50
Ω
: 0.5W to 8W (Internally calculated from Amplitude)
Repetition Rate: Single manually-triggered event, max repetition rate 0.3Hz.
UUT Scope Trigger: With energy pulse, or Auto trigger at 100Hz
• Zero Skew Function:
Frequencies: 10Hz to 100MHz.
Default Alignment: 9500B output channel skew = ≤50ps.
Align 9500B Channel Output Timing: Using a single oscilloscope channel.
Measure UUT Scope Channel Skew: Using aligned 9500B channels.
• Auxiliary Input:
Signal Path: Automated, passive, relay-switched routing of user's external
calibration waveforms to any Active Head's BNC connector
via the output multiplexer.
Impedance: Input and Output: 50Ω.
3dB Bandwidth: Approx. 400MHz.
Trigger: No trigger pickoff provided, internal trigger not available.
• Load Resistance and Capacitance Measurement:
Resistance Range
:
Input: 10kΩ to 20MΩ.
Termination:10Ω to 150Ω.
Capacitance
:
Range: 1pF to 120pF.
• Reference Frequency Input:
Frequency Range: 1MHz to 20MHz in 1MHz integer steps.
Amplitude Range: 70mV pk-pk to 1V pk-pk.
• Reference Frequency Output:
Frequency Range: 1MHz or 10MHz.
Level into 50
Ω
: >1.15V.
Level into 1M
Ω
: >2.3V.
• Input Leakage Function:
Short/Open Circuit Outputs: Allows testing of UUT oscilloscope input leakage
current.
UUT Scope Trigger: Auto trigger at 100Hz
• DC Function:
Output Voltage: (into 50Ω): ±(888µV to 5.56V)
Output Voltage: (into 1MΩ): ±(888µV to 222.4V)
• Square Function:
Frequencies: 10Hz to 100kHz
Output Voltage: (pk-pk into 50Ω): 35.52µV to 5.56V
Output Voltage: (pk-pk into 1MΩ Load): 35.52µV to 222.4V
• Sine Function (Variant 9500B/1100 quoted below);
(see Sect. 7 for specifications of other variants):
Frequencies: 100mHz to 550MHz
Output Voltage: (pk-pk into 50Ω & 1MΩ): 4.44mV to 5.56V
Frequencies: 550MHz to 1.1GHz
Output Voltage: (pk-pk into 50Ω & 1M): 4.44mV to 3.35V
Dual Channel
• Edge Function: Selectable Rising/Falling Edge
Low Edge
: 500ps: Active Head Model 9510 or 9530
Periods: 500ns to 100ms
Output Voltage: (pk-pk into 50Ω &1MΩ): 4.44mV to 3.1V
High Edge
: 100ns: Active Head Model 9510 or 9530
Periods:10µs to 100ms
Output Voltage: (pk-pk into 50Ω): 888mV to 5.56V
(pk-pk into 1MΩ): 888mV to 222.4V
Fast Edge
: 150ps: Active Head Model or 9530
Periods: 500ns to 100ms
Output Voltage: (pk-pk into 50Ω &1MΩ): 4.44mV to 3.1V
• Time Markers Function (Output Voltage pk-pk into 50Ω & 1M)
Square/Sine Waveforms
(Variant 9500B/1100 quoted below)
;
(see Sect. 7 for specifications of other variants):
Squarewave Periods: 9.0091ns to 55s (111MHz to 18.181mHz)
(Highlighted style): 20ns to 55s (50MHz to 18.181mHz)
Output Voltage: 100mV to 1.0V
Sinewave Periods: 450.5ps to 9.009ns (2.22GHz to 111MHz)
Output Voltage: 100mV to 500mV
Sinewave Periods: 909.1ps to 9.009ns (1.1GHz to 111MHz)
Output Voltage: 1.0V
Pulse and Triangle Waveforms
:
Periods: 900.91ns to 55s (1.11MHz to 18.181mHz)
(Highlighted style): 20ns to 55s (50MHz to 18.181mHz)
Output Voltage: 100mV to 1.0V
• Pulse Width Function:
Amplitude: 1Vpk-pk into 50W
Pulse Width: 1ns to 100ns
Rise/Fall Time: <500ps
Frequency: 1kHz to 1MHz
• Current Function:
DC
:
Output Current: ±(88.8µA to 111.2mA)
Square
:
Frequencies: 10Hz to 100kHz
Output Current: 88.8µA pk-pk to 111.2mA pk-pk
1.2.1 Functions (Contd.)
