Appendix F to Section 6: 9500B System Operation — Emulation of Tektronix SG5030 and CG5010/5011 6-F7
Table 6.F.5.1 — CG5010/5011 Command Emulation by 9500B (Contd.)
RPT?
Repeats the most-recent message sent. √
RQS ON|OFF
Turns on or off the SRQ generations. √
RSHF
Increments the shift counter by 1. X
SET?
Returns settings of instrument in settings-dependent format: +
As CG5011
S/D <NR3>S
Sets Markers mode, if not already selected, and then sets the seconds per division value. √
SHIFT <NR1>
Sets shift counter argument. X
SRQ?
Returns the reason for SRQ. X
TEST
Activates the instrument power-on selftest routine (takes about 5 secs). X
TRIG ON|OFF|NORM|X.1|X.01
ON
= Turns TRIGGER OUTPUT on. √
OFF
= Turns TRIGGER OUTPUT off. √
NORM
= Sets trigger rate to the same as the output signal rate (Power-on default). √
X.1
= Sets trigger rate to 1/10 of the output signal rate. √
X.01
= Sets trigger rate to 1/100 of the output signal rate. √
TSET?
Returns the ASCII word 'NULL' message. X
U/D <NR3>
Sets the desired units per division. √
U/D?
Returns the present <NR3> units per division. √
U/D <NR3>
UMSK <NR1>
Unmasks an error that was masked, opposite to the
MASK
command. X
VAR
Sets instrument to display DUT percent error readout. √
VERS?
Returns a version ID code. +
VERS 0000FFFF
V/D <NR3>V
Sets the instrument to voltage and desired number of units/division. √
ZSHF
Resets the shift counter to zero. X
CG5010/5011 CG5010/5011 Command Description 9500B 9500B Response
Command Emulation
