Section 9: Verifying the Model 9500B Accuracy Specification 9-9
Final Width = 215mm
Verif. Frequency Output Absolute Tolerance Output Absolute Tolerance Measured
Point. Voltage Limits (pk-pk) Voltage Limits (RMS) Value
(pk-pk) Lower Higher (RMS) Lower Higher (RMS)
-SQ1 1kHz 600.00mV 599.39mV 600.61mV 299.9979mV 299.67mV 300.28mV
-SQ2 1kHz 60.000mV 59.93mV 60.07mV 29.99799mV 29.96mV 30.03mV
-SQ3 1kHz 6.0000mV 5.984mV 6.016mV 2.999799mV 2.992mV 3.008mV
-SQ4 1kHz 6.0000V 5.99399V 6.00601V 2.999799V 2.99674V 3.00275V
-SQ5 1kHz 60.000V 59.93999V 60.06001V 29.99799V 29.96750V 30.02751V
Table 9.8.2.2 DC/Square Square (-) Verification at 1kHz into 1M Ω Load
Please copy the following table.
Enter the measurements in the Measured Value column on the copy:
Verif. Frequency Output Absolute Tolerance Output Absolute Tolerance Measured
Point. Voltage Limits (pk-pk) Voltage Limits (RMS) Value
(pk-pk) Lower Higher (RMS) Lower Higher (RMS)
±SQ1 1kHz 600.00mV 599.39mV 600.61mV 299.9979mV 299.67mV 300.28mV
±SQ2 1kHz 60.000mV 59.93mV 60.07mV 29.99799mV 29.96mV 30.03mV
±SQ3 1kHz 6.0000mV 5.984mV 6.016mV 2.999799mV 2.992mV 3.008mV
±SQ4 1kHz 6.0000V 5.99399V 6.00601V 2.999799V 2.99674V 3.00275V
±SQ5 1kHz 60.000V 59.93999V 60.06001V 29.99799V 29.96750V 30.02751V
Table 9.8.2.3 DC/Square Square (Symmetrical) Verification at 1kHz into 1M Ω Load
Please copy the following table.
Enter the measurements in the Measured Value column on the copy:
