Section 9: Verifying the Model 9500B Accuracy Specification 9-27
Final Width = 215mm
Table 9.9.2.3 Sine FlatnessVerification at 300mV p-p into 50 Ω Load
Verif Nominal Output Measured Specification User's Total Flatness Validity Tolerance Measured p-p
Point. Output Frequency p-p Voltage Relative to Measurement Limits Voltage for
Voltage at 50kHz 50kHz Uncertainty Flatness
(% of Output) (Um) Lower Higher Check
Ref 3 300mV 50kHz
SF26 10MHz ±2.0
SF27 50MHz ±2.0
SF28 100MHz ±2.0
SF29 250MHz ±2.0
SF30 400MHz ±2.5
SF31 550MHz ±2.5
SF32 600MHz ±2.5
SF33
†
725MHz ±3.5
SF34
†
1GHz ±3.5
SF35
††
1.5GHz ±4.0
SF36
††
2GHz ±4.0
SF37
††
2.5GHz ±4.0
SF38
††
3GHz ±4.0
SF64
†††
4GHz ±4.0
SF65
†††
5GHz ±4.0
SF66
†††
5.5GHz ±4.0
SF67
†††
6GHz ±4.0
Additional verification points for: 9500B/1100 & 9500B/3200 (†); 9500B/3200 only (††) and 9500B/3200 with 9560 (†††).
