0-6 Model 9500B User's Handbook — Contents List
Page
Section 9 Verifying the Model 9500B Specification
9.1 About Section 9 ............................................................................................................ 9-1
9.2 Need for Verification ..................................................................................................... 9-1
9.2.1 Factory Calibration and Traceability ................................................................. 9-1
9.2.2 Verification on Receipt from the Factory .......................................................... 9-1
9.2.3 Verification after User-Calibration .................................................................... 9-1
9.3 Equipment Requirements ............................................................................................. 9-1
9.4 Interconnections ........................................................................................................... 9-1
9.5 Verification Points ......................................................................................................... 9-1
9.6 Specification Limits ....................................................................................................... 9-2
9.7 Verification Procedure .................................................................................................. 9-2
9.8 9500B Mainframe Verification by Functions
9.8.1 Verifying the DC/Square Function: DC Voltage ............................................... 9-2
9.8.2 Verifying the DC/Square Function: Square Voltage ......................................... 9-6
9.8.3 Verifying the LF Sine Voltage Function ............................................................ 9-10
9.8.4 Verifying the Time Markers Function ................................................................ 9-13
9.8.5 Verifying the Load Resistance Measurement Function .................................... 9-15
9.8.6 Verifying the Pulse Width Function .................................................................. 9-18
9.9 9510/9530/9550/9560 Head Verification by Functions
9.9.1 Verifying the Levelled Sine Voltage Function: LF Gain .................................... 9-20
9.9.2 Verifying the Levelled Sine Voltage Function: Flatness ................................... 9-23
9.9.3 Verifying the Edge Function ............................................................................. 9-29
9.9.4 Verifying the Load Capacitance Measurement Function ................................. 9-33
Section 10 Calibrating the Model 9500B
10.1 About Section 10 and Section 10 Contents ................................................................. 10.1-1
10.2 9500B Mainframe Calibration and Active Head™ Calibration ..................................... 10.2-1
10.2.1 Introduction ...................................................................................................... 10.2-1
10.2.2 Mainframe Unit Calibration .............................................................................. 10.2-1
10.2.3 Active Head Calibration ................................................................................... 10.2-1
10.2.4 Other Functions .............................................................................................. 10.2-1
10.2.5 Mainframe Unit Manual Calibration ................................................................. 10.2-1
10.3 The Model 9500B Calibration Mode ............................................................................. 10.3-1
10.3.1 Introduction ...................................................................................................... 10.3-1
10.3.2 Mode Selection ................................................................................................ 10.3-2
10.3.3 Selection of Calibration Mode .......................................................................... 10.3-2
10.3.4 Special Calibration ........................................................................................... 10.3-3
10.3.5 Special Cal: 'Adjust FREQ' ............................................................................... 10.3-4
10.3.6 Mainframe Standard Calibration (STD CAL) .................................................... 10.3-5
10.3.7 Overview of Calibration Operations ................................................................. 10.3-6
10.4 Standard Calibration — Basic Sequences .................................................................... 10.4-1
10.4.1 Introduction ...................................................................................................... 10.4-2
10.4.2 Target Selection Screen — Selecting Hardware Configurations ..................... 10.4-2
10.4.3 The Adjustment Screen .................................................................................... 10.4-3
10.4.4 Calibrating the Model 9500B at Target Values ................................................. 10.4-4
10.4.5 Standard Calibration of AC Functions .............................................................. 10.4-5
10.4.6 Exit from Calibration - Cal Date and Cal Due Date .......................................... 10.4-6
