Rev 4/2018
49
PRE STARTING CHECKS
7. Move Ground Speed switch to field position
(see Figure 62).
Road
Field
Stop
to change
Figure 62. Ground Speed Switch
CAUTION
Loss of Control.
Can result in impact that could cause injury
or equipment damage.
Bring machine to a complete stop before
shifting gears between FIELD to ROAD
modes.
8. Move engine speed switch to low throttle posi-
tion (see Figure 63).
Throttle
High throttle
position
Low throttle
position
Figure 63. Engine Speed Switch
9. Move the Baler Drive Switch (see Figure 64)
to the OFF position (disengaged).
On
Off
Baler
Figure 64. Baler Drive Switch
10. Place hydrostatic drive control ever in neutral
park position (see Figure 65 on page 50).
11. Make sure steering wheel is locked in centered
position.
To Next Page
