4 Fax
132
Fax
4
1 Select [Reduce/Enlarge].
2 Select a preset ratio or specify a
value.
Note • Initial values for ratio other
than [100%] and [Auto %]
can be changed. For more information, refer to "Reduce/Enlarge Presets" (P.319).
• If a magnification is specified in [Reduce/Enlarge], automatic rotation transmission does not
work. For information about the feature, refer to "Rotate 90 Degrees" (P.315).
îš„100%
Scanned at the same size as the original.
îš„Auto %
If the scan width of the document is greater than the maximum image size, the
scanned image is rotated or reduced to fit the maximum image.
When speed dialing is used, the maximum image size will be the size registered in
Address Number. When speed dialing is not used, the size will be A3.
You can specify whether to rotate documents in the System Administration mode. For more information,
refer to "Rotate 90 Degrees" (P.315).
îš„Variable %
Touch the window displaying a value, and then use the numeric keypad or the [ ] and
[ ] buttons to specify a ratio within the range of 50 - 400% in 1% increments.
To Next Page
