14 Maintenance
430
Maintenance
14
Executing Calibration
The machine automatically adjusts gradation when the density or color reproducibility
in copies and prints has deteriorated. Gradation can be adjusted for each screen type.
The machine offers the following four screen types:
z
[Copy Job - Text]
Adjusts the gradation for copying text documents.
z
[Copy Job - Photo]
Adjusts the gradation for copying photos.
z
[Print Job - Text]
Adjusts the gradation for printing text documents.
z
[Print Job - Photo]
Adjusts the gradation for printing photos.
Important • Because the Tray 5 (Bypass) is used for calibration, load plain paper in the Tray 5 (Bypass).
Any other types of paper are not available. For more information, refer to "Paper Size/Type"
(P.277).
Note • It is recommended that you perform adjustments for all the screen types. After one screen
type is adjusted, specify another screen type and repeat the adjustment procedure.
• If color gradation is not compensated despite the periodic calibration, contact our Customer
Support Center.
• Calibration does not execute when [Text] or [Map] is selected for [Original Type] in the
[Image Quality] tab for copying. Before calibration, make sure that [Copy Defaults] in the
System Administration mode is set as follows: Lighten/Darken: Normal, Color Shift: Normal,
Saturation: Normal, Color Balance: 0. After finishing the calibration, change the settings of
[Copy Defaults] if necessary. For information about the [Copy Defaults], refer to "Copy
Defaults" (P.293).
1 Press the <Log In/Out> button.
Note • The calibration can also be
performed through the menu
screen. Clicking [Calibration]
on the menu screen displays
the screen shown in step 9.
2 Enter the user ID with the numeric
keypad, and select [Confirm].
Note • The default user ID is "11111".
When using the
Authentication feature, a
passcode is required. The
default passcode is “x-admin”.
3 Select [System Settings].
123
456
789
0 #
C
<Log In/Out>
button
To Next Page
