Replacing Consumables
415
Maintenance
14
10 Hold the center section of the new
waste toner container, and adjust
the center position to insert the
container into the machine.
11 Hold the left and right orange
levers to close the black cover.
12 Close the front cover.
Note • A message will be displayed and the machine will not operate if the front cover is not
completely closed.
Replacing Drum Cartridge [A1], [A2], [A3], or [A4] (for customers having a
spot maintenance contract)
When it is time to replace the drum cartridge, a message "Please order a new xxx drum
(AX) (Maintenance Request)" appears on the display. When this message appears,
contact our Customer Support Center.
If you have a spot maintenance contract, refer to this section to identify the indicated
drum cartridge location ([A1], [A2], [A3], or [A4]) and replace the drum cartridge.
If you continue to use the machine without replacing the cartridge even after the
message appears, the machine will stop and copying or printing will no longer be
possible when the number of printed/copied pages reaches the following:
z
ApeosPort-II C2200, DocuCentre-II C2200:
Approx. 1,000 pages for yellow/magenta/cyan
Approx. 1,100 pages for black
z
ApeosPort-II C3300, DocuCentre-II C3300:
Approx. 1,700 pages for yellow/magenta/cyan
Approx. 1,800 pages for black
z
ApeosPort-II C4300, DocuCentre-II C4300:
Approx. 3,400 pages for yellow/magenta/cyan
Approx. 3,800 pages for black
Important • The use of drum cartridges not recommended by Fuji Xerox may impair quality and
performance. Use only drum cartridges recommended by Fuji Xerox.
Note • Do not expose drum cartridges to direct sunlight or strong light from indoor fluorescent
lighting. Do not touch or scratch the surface of the drum cartridge. Doing so may result in
unsatisfactory printing.
• Replace the drum cartridge while the machine is switched on. If the power is turned off, all
information stored to the machine's memory will be erased.
To Next Page
