Fujitsu Airstage V series User Manual

Ref Description Part No. Ref Description Part No.
No. AJ*126UBTF No. AJ*126UBTF
1 FAN COVER 9377941015 100 CONTROL BOX 9373932017
2 BELL MOUTH 9361721005 101 CONTROLLER PCB ASSY 9705653023
3 EMBLEM (FUJITSU) 9371388014 102 COMMUNICATION PCB 9704424044
4 SIDE PANEL- L ASSY 9362940023 104 CAPACITOR (FAN MOTOR) 9900269180
5 SIDE PANEL- R ASSY 9362941037 105 MAGNETIC RELAY 9900116019
6 FRONT PANEL- L 9361709027 106 TERMINAL 5P 9900251017
7 FRONT PANEL- R 9374339020 107 TERMINAL 3P 9703345012
8 FRONT PROTECTION NET 9377939012
9 REAR PANEL ASSY 9362943031
10 CONDENSER GUARD 9377940018
110 CONTROL BOX COVER ASSY 9375204013
11 BASE ASSY 9372336021
12 BASE FOOT PAINTED 9361688025
13 RFM (SIDE PANEL) ASSY 9362955027
14 SEPARATE WALL- L 9373917014
15 SEPARATE WALL- R ASSY 9362948050
16 BRACKET (VALVE)- A 9373926016
17 RFM(SEPARATE WALL) 9361697003
18 BRKT PNL (S VLV) 9364230009
19 SEPARATE WALL TOP ASSY 9362942058
21 CONDENSER A SUB ASSY 9362954174
26 BRACKET (CONDENSER)-L ASSY 9362958028
27 BRACKET (CONDENSER)-R ASSY 9362959032
28 BRACKET(MOTOR) A ASSY 9362960021
29 CONDENSER B SUB ASSY 9362956062
34 BRACKET(MOTOR) B ASSY 9362963022
35 DRAIN PAN ASSY 9362961028
36 BRACKET PANEL (MOTOR) 9361703001
37 FAN MOTOR ASSY-OUTER 9602003013
38 PROPELLER FAN 9361726000
39 BRACKET (CONTROL BOX) 9361727007
40 THERMISTOR (H.E) 9900099039
41 THERMISTOR SPRING A 313728262708
42 BUSHING 9361725003
44 BRACKET (THERMISTOR) 9373154013
50 GASKET 9375556013
52 FLANGE ASSY 9373983026
54 INSULATION (PIPE) C 9363828009
AJ*126UBTF
Model :
08-10
55
RFM CHASSIS A
9374790012
56
RFM CHASSIS B
9374790029
111
112
BAND (CAPACITOR)
RELAY
9373942023
9900294014
