Fujitsu Airstage V series User Manual

Ref Description Part No. Ref Description Part No.
No. AJ*126UBTF No. AJ*126UBTF
201 COMPRESSOR ASSY 9374250011
202 BELT HEATER A 240V 35W 9361140189
203 BELT HEATER B 240V 35W 9361140196
204 BELT HEATER C 240V 35W 9361140202
205 TERMINAL COVER (COMP) 9372760017
206 BRKT PNL (COMP) ASSY 9373923015
208 RUBBER SEAT (COMP) 9372761021
209 COMPRESSOR COVER-A 9374243020
212 COMPRESSOR COVER-D 9374243013
213 BRACKET (COMPRESSOR) 9361694002
220 OIL SEPARATOR ASSY 9373991021
325 JOINT PIPE (BYPASS) ASSY 9375657024
230 RECEIVER TANK ASSY 9373993025 330 OIL RETURN VALVE ASSY 9375561031
331 CAPILLARY TUBE 9374001095
240 ACCUMULATOR ASSY 9373995036
250 DISCHARGE PIPE ASSY 9375557034
334 SOLENOID VALVE SV8-1,2,3 9970046018
251 CHECK VALVE 9372198056
335 STRAINER 9373588122
260 JOINT PIPE E ASSY 9375018016
336 DISTRIBUTOR 9304394006
270 EXPANSION VALVE ASSY 9374811038
337 NOZZLE 9304395003
271 STRAINER 9371191010
288 STRAINER 9372951033
289 RELIEF VALVE 9375660017
272 CHECK VALVE 9372198063
280 SUB COOL HEX ASSY 9374807017
281 STRAINER ASSY 9372524015
282 EXPANSION VALVE 9900056025
274 EXPANSION VALVE 9900170035
283 JOINT PIPE (SUB COOL HEX) A ASSY 9374381029
284 JOINT PIPE (SUB COOL HEX) B ASSY 9374809028
285 CHECK VALVE 9372198063
286 SOLENOID VALVE SV4 9970041013
290
291
300 SUCTION PIPE A ASSY 9375559045
302 SUCTION PIPE B ASSY 9375559052
304 SUCTION PIPE C ASSY 9375559069
AJ*126UBTF
Model :
08-11
310 BYPASS A ASSY
9374957019
311 SOLENOID VALVE SV1,2 9970038013
312 SOLENOID VALVE SV3,5 9970040016
313 CHECK VALVE
9312268009
314
CAPILLARY ASSY (SV5)
9375636012
320
BYPASS B ASSY
9374959013
322
CAPILLARY TUBE 9374001101
323
CHECK VALVE
9312268009
326
CHECK VALVE
9312268009
324 SOLENOID VALVE SV6,7 9970046018
340 CAPILLARY ASSY 9373979029
341 STRAINER 9373588115
350 PRESSURE PORT ASSY
9373969020
351 CHECK JOINT ASSY
9372802038
360 3WAY VALVE ASSY (OIL)
9372205129
361 3WAY VALVE ASSY (LIQUID)
9372205136
370 BRACKET (PIPE BAND) ASSY
9374362011
371 CUSHION
9374366019
372 PIPE BAND
9374365012
400 THERMISTOR (TH1,2,3,11,12) ASSY
9900247010
401 THERMISTOR (TH5,6,7,8,9) ASSY
9900249014
402 THERMISTOR (TH10)
9900099046
403 THERMISTOR (TH13)
9900099053
404 THERMISTOR SPRING A
313728262708
410 SOLENOID SV1
9900189037
411 SOLENOID SV2
9900189044
412 SOLENOID SV3
9970044038
413 SOLENOID SV4
9970044014
414 SOLENOID SV5
9970044021
415 SOLENOID SV6
9900189105
416 SOLENOID SV7
9900189068
450 SOLENOID 4WV
9970045011
417 SOLENOID SV8-1
9900189075
418 SOLENOID SV8-2
9900189082
419 SOLENOID SV8-3
9900189099
420 PRESSURE SENSOR
9900253011
430 COIL (EXPANSION VALVE)
9900197025
431 COIL (EXPANSION VALVE)
9900190040
440 VALVE PLATE
9375555016
BINDER CB
9374569021
BINDER LB
9305335008
PIPE COVER
9363470000
4WAY VALVE ASSY 9374806010
3WAY VALVE ASSY (GAS) 9373989035
292 STRAINER 9375130022
293 STRAINER F 9365441008
294 4WAY VALVE 9970042010
