The aliases are assigned according to the following schema:
2.3.1.4 ACL functionality
You can lock or release individual TCP/UDP ports (services) for the DANPU<xx>, MANPU,
MONPU, DANPR<xx>, and MONPR<xx> networks in an ACL (Access Control List):
– Either the administrator defines an ACL list of the type "permit" in which all released
services (ports) are explicitly entered.
i After the ACL of the type "permit" has been configured, the list is initially
empty. Access to the network is thus locked for all services (ports).
– Or the administrator defines an ACL list of the type "deny" in which all the locked
services (ports) are explicitly entered.
One ACL list each can be defined for IPv4 and IPv6.
Component MCNPR SE alias
(x=1..n; y=1..8; z=01..99)
Description
MU mu<x>-se<y>.senet M2000
SU /390 su0bs2-se<y>.senet BS2000 (Native/monitor VM)
su0vm<z>-se<y>.senet BS2000 VMs
SU x86 su<x>-se<y>.senet X2000
su<x>irmc-se<y>.senet SU x86 iRMC
su<x>bs2-se<y>.senet BS2000 (Native/monitor VM)
su<x>vm<z>-se<y>.senet BS2000 VMs
Managed Switch nswa<x>-se<y>.senet nswa = 1 Gbit
nswb<x>-se<y>.senet nswb = 10 Gbit
HNC hnc<x>-se<y>.senet HNC
hnc<x>irmc-se<y>.senet HNC iRMC
AU PY au<z>-se<y>.senet System (e.g. VMware)
AU PQ auc<z>-se<y>.senet Management Board of a PRIMEQUEST
auc<z>p<nr>se<y>.senet Partition of a PRIMEQUEST
RAID system prd<z>-se<y>.senet e.g. ETERNUS DX (prd=periphery raid)
Tape library ptl<z>-se<y>.senet e.g. LT40 S2 (ptl=periphery tape library)
Other periphery pot<z>-se<y>.senet (pot=periphery other)
ROBAR rob<z>-se<y>.senet ROBAR controller
Table 2: Name schema of the SE aliases
