SE Manager interface Operating the SE Manager
80 U41855-J-Z125-3-76
3.3.2 Main window
The main window of the SE Manager opens as soon as you have logged in on the SE
Manager. The next two figures provide an example to name the areas in the main window
and the principle controls.
SE Manager: areas in the main window
1: Tree structure
Main menus for selecting objects which are displayed in the working area
2: Tabs
Tabs for selecting objects which are displayed in the working area.
If the main window supports automatic updates, the Update icon (wheel) is
displayed on the right-hand edge. During an update, the wheel is rotating.
Otherwise it is greyed out.
