Managing devices Managing BS2000 devices
U41855-J-Z125-3-76 169
Dokuschablonen 19x24 Version 7.4de für FrameMaker V7.x vom 09.02.2010 © cognitas GmbH 2001-2010
19. March 2018 Stand 18:25.48 Pfad: P:\FTS-BS\Server\SE-Server\SE-Doku\1303912_BuV_062\BuV_e\buv.k09
On the HNC the following BS2000 devices are predefined for the SU /390:
i In case of a Management Cluster, these BS2000 devices are predefined on MU and
HNC for the SU /390 on both SE servers as described above.
9.1.2.2 Device connection via Management Unit and HNC
When a device is added, in the first step the MU or HNC on which the device is emulated
must be specified:
● You can manage (add, change, remove) LAN devices (ZASLAN and LOCLAN) of an
SU /390 via the HNC, see, for example, “Add new LAN device” on page 180.
● You can manage KVPs, LAN devices (LOCLAN), and emulated tape devices via the
MU.
In the case of MU redundancy on MU2 (MU index 2):
EMDISK CDF0_CDF1 00 F0_F1 optional: 2 emulated disks (e.g. for BS2000
emergency system)
KVP C4_C5 00 C3_C4 Name: HV0
LOCLAN CD80_CD81 00 80_81 Name: MANLO1
IP address: 192.168.139.21
Address space: 192.168.139.xx
CDROM TA 00 60 Real CD-ROM drive
EMFILE TB 00 61 emfile0061
Type MN HC LUN Details
LOCLAN - - - -
Address space: 192.168.151.xx
ZASLAN CC40_CC41 00 40_41 Name: MCNPR
Slot: s2 p0 pci
In the case of HNC redundancy on HNC2:
LOCLAN - - - -
Address space: 192.168.152.xx
ZASLAN CD40_CD41 00 40_41 Name: MCNPR
Slot: s2 p0 pci
Table 5: Predefined BS2000 devices on SU /390 (HNC)
Type MN HC LUN Details
Table 4: Predefined BS2000 devices on SU /390 (MU) (part 2 of 2)
