2.7.2.4 XenVM devices
When a XenVM is created, not only the main memory and CPUs are configured, but also
virtual devices. From the viewpoint of the guest system (Linux/Windows), these devices
look like real devices. To enable the guest system to recognize and use the devices
configured on the XenVM, the corresponding device drivers must be installed in the guest
system.
Figure 10: Configuring XenVM devices on the XenVM
vCPU(s)
Main Virtual
Disk
Virtual
DVD
Virtual Virtual
ConsoleMemory
XenVM
XenVM
Devices
disk02disk01
free
poolx
xvda xvdb
Disks Installation Sources Networks
Internal
vSwitch
External
vSwitch
Uplink
(eth/bond)
CPU Pools
Main Memory
Linux/Windows Pool
Used Free
VM Resources
NIC
Drive
Application Pool
