Managing devices Managing BS2000 devices
U41855-J-Z125-3-76 171
Dokuschablonen 19x24 Version 7.4de für FrameMaker V7.x vom 09.02.2010 © cognitas GmbH 2001-2010
19. March 2018 Stand 18:25.48 Pfad: P:\FTS-BS\Server\SE-Server\SE-Doku\1303912_BuV_062\BuV_e\buv.k09
9.1.3 Device management on Server Unit x86
On an SU x86 all the BS2000 devices (disks, KVP, LAN devices, tape devices) are
emulated in X2000.
The devices are managed on the SU x86 concerned.
When devices are added, device licenses may need to be taken into account.
9.1.3.1 Predefined BS2000 devices
The following BS2000 devices are predefined on SU x86:
9.1.3.2 Connection of peripheral devices
When BS2000 devices which reside on peripheral devices (disks, tapes) are configured, as
a rule not only the X2000 level plays a role, but also other levels.
The various levels are explained on the basis of an example of a connected (via
FibreChannel) disk storage system:
● The BS2000 disks are mapped on Linux disks.
● The Linux disks are operated via one or more FibreChannel HBAs (Host Bus Adapters).
● The SU x86 is connected to the disk storage system either directly or via a
FibreChannel switch.
Type MN HC Unit ID Details
Disk D0 00 08 Internal disk; generated as standby pubset
KVP Z0_Z1 00 04_05 Name: HV0
LOCLAN CC80_CC81 0C 80_81 Name: MANLO1
Address: 192.168.138.21
Address space: 192.168.138.xx
ZASLAN CC40_CC41 0C 40_41 Name: MCNPR
Slot: s1 p0 pci
CDROM CD 00 CD Real CD-ROM drive
EMFILE EF 00 EF emfile00ef
Table 6: Predefined BS2000 devices on SU x86
