207
PRIMERGY TX120 User’s Guide
8
Configuring Hardware and utilities
CPU Status Submenu
This submenu sets whether or not to allow the use of the installed CPU.
Memory Status Submenu
This submenu sets whether or not to allow the use of the installed memory.
ASR&R Boot Delay
• 2 (Initial value)
•1–30
Sets the standby time for startup after shutdown due
to trouble (such as overheating) in minutes.
The system restarts after the set standby time. The
power LED lights in green in standby mode.
Power Cycle Delay
• 7 (Initial value)
•0-15
Sets the time until the server is turned on after it is
turned off.
Boot Retry Counter
• 3 (Initial value)
•0–7
Sets the maximum number of retries to boot the
operating system within the range of 0 to 7.
Diagnostic System
Disabled (Unchangeable) Sets whether or not to diagnose the BootDevice
when restarting with ASR&R.
Next Boot uses Boot option (Unchangeable) Sets the boot device for restarting.
Device Instance 0 (Unchangeable) Sets the device ID of LAN Boot Device diagnosis.
Temperature Monitoring
Disabled (Unchangeable) Sets whether or not the server can be turned on when
the temperature is not in its operating environment
range (10-35 °C).
CPU Status
Press the [Enter] key to display the "
CPU Status Submenu" (Jpg.207) window.
Memory Status
Press the [Enter] key to display the "
Memory Status Submenu" (Jpg.207)
window.
Console Redirection
Press the [Enter] key to display the "
Console Redirection Submenu" (Jpg.208)
window.
table: Items on the CPU Status Menu
Item Setting Description
CPU 0 Status Enabled (Unchangeable) Sets whether or not to allow the use of CPUs installed
in CPU Socket 0.
table: Items on the Memory Status Menu
Item Setting Description
DIMM-1A Enabled (Unchangeable) Sets whether or not to allow the use of memory in
Memory Slots 1A to 2B.
DIMM-2A
DIMM-1B
DIMM-2B
table: Items on the Server Menu
Item Setting Description
