26
Chapter 1 Overview
c Mouse connector ( )
A mouse is plugged in.
d Keyboard connector ( )
A keyboard is plugged in.
e Display connector ( )
A display cable is plugged in.
f Serial port connector ( )
Cables of peripheral equipment conforming to the RS-232C standard such as modems are
plugged in.
g Remote Management Controller port
This is a port for the Remote Management Controller. The Remote Management function can be
used from Web interface by connecting a LAN cable. For information on how to use the Remote
Management Controller, refer to "D Remote Management Controller" (
Jpg.252).
h LAN (10/100/1000BASE-T) port ( )
An Unshielded Twisted Pair (UTP) cable is plugged in.
For 1000Mbps connection, a category 5 enhanced or a category 6 cable is required.
For 10Mbps/100Mbps connection, a category 5 or higher cable is required.
The meaning of the LED is shown in the table below.
i USB connector ( )
Connects peripheral equipment conforming to the USB standard (2.0 or 1.1).
table: Meaning of the LAN Port LED
LED
location
LED status Connection status
Upper LED Lights in green Link is being established
Blinks in green Data is being transferred
Off Link is not established
Lower LED Lights in amber Connection established at 1000 Mbps
Lights in green Connection established at 100 Mbps
Off Connection established at 10 Mbps
LED
To Next Page
