A Server Specifications
A Server Specifications
This section explains the specifications for the server.
The specifications for this server are liable to be updated without any notice. Please be forewarned.
table: Server Specifications
Item Functions and Specifications
Model TX120
Hard Disk Hot Plug Yes
CPU
modules
Clock
Intel
®
Xeon
®
3040 Processor 1.86GHz / 2MB / Dual Core
(Intel
®
Xeon
®
3070 Processor 2.66GHz / 4MB / Dual Core)
FSB 1066MHz
Number of
multiplication
1
Memory
Standard 512MB (DDR2 533 Unbuffered Lowprofile DIMM × 1)
Adding size 512MB / 1GB / 2GB
Maximum 8GB (2GB × 4)
Graphics
VGA chip: built-in iRMC 640x480, 800x600, 1024x768, 1280 × 1024
Displayed colors: Differ depending on resolution and OS
Expansion slots
(LowProfile)
PCI 32bit / 33MHz (LowProfile) × 1
PCI-Express by four (with x8 connector) × 1
PCI-Express by one (short) × 1
Floppy disk drive
No
Use the floppy disk drive of USB connection..
Hard disk
drive
bay 2 bays (2.5 inch)
I/F SAS
Maximum 146.8GB (73.4GB× 2)
Optional
drive
Standard CD-ROM Drive unit
Optional Internal DAT 72 unit (USB)
Onboard
controller
SAS LSI Logic 1064E (IME)
LAN Broadcom BCM5754 × 1 (GbE)
VGA iRMC / 1.7MB Video RAM
External
I/O port
Monitor 1 (Analogue RGB DSUB 15PIN)
Keyboard 1 (PS / 2 miniDIN 6PIN)
Mouse
1 (PS / 2 miniDIN 6PIN）
Serial 1 (DSUB 9PIN)
Parallel No
USB
4 (Front × 2、Rear × 2）
LAN 1 (Modular (RJ-45) 8PIN)
Power supply unit Standard × 1, Maximum × 1 (No redundant configuration)
Fan No redundant configuration
Power consumption Max. 175W / 630kJ/h
Power 100-127 / 200-240 V AC (50-60Hz)
Weight 10kg
Dimensions (Width ×
Depth × Height (mm))
99 × 399 × 340
OS
Windows Server 2003 R2, Standard Edition / Windows Server 2003, Standard Edition /
Windows Server 2003 R2, Standard x64 Edition / Windows Server 2003, Standard x64 Edition /
Red Hat Enterprise Linux ES (v.4 for x86) / Red Hat Enterprise Linux ES (v.4 for EM64T)
