Fujitsu Primergy TX120 - How to Install Memory Modules

166
Chapter 7 Installing Hardware Options
7.3.3 How to Install Memory Modules
1 Turn off the server and connected devices, and unplug all power cables from
the outlet.
2 Remove the cover.
J"7.2 Removing and Attaching the Side Cover" (pg.162)
3 Touch a metal part of the server to discharge static electricity.
4 Remove a reinforcing bar.
` It may be difficult to install the memory modules depending on the location of the memory slots
because of the peripheral devices. In this case, remove a unit bay. For removing it, refer to
"7.6.3 How to Install an Internal DAT72 Unit" (Jpg.179).
5 To replace the memory module, open outward the retention clips on both sides
of the slot.
• Make sure not to open the clips outward too quickly because the
memory module may pop up, which could cause damage.
