Fujitsu Primergy TX120 User Manual

148
Chapter 5 Operations after OS Installation
5.7 LAN Driver Advanced Setup
[Intel
®
PROSet]
"Intel
®
PROSet" is a tool for configuring details on the LAN driver. This is used in the
following cases.
• Use the Teaming function between LAN cards or between a LAN card and the
onboard LAN
• Setup a VLAN using a LAN card
• Perform the other advanced setups of a LAN card
Use of BACS
` Use BACS (Jpg.143) to perform the following advanced setups of the onboard LAN:
• Setup a VLAN using the onboard LAN
• Perform the other advanced setups of the onboard LAN
5.7.1 Intel
®
PROSet Installation
If the tabs such as [Link], [Teaming] and [VLANs] are not displayed in the property of LAN adapters
which can be selected from the [Device Manager], install Intel
®
PROSet according to the following
installation procedures:
1 Execute the following file contained in the ServerStart Disc 1 CD-ROM.
For Windows Server 2003 x64
[CD-ROM drive]:\Tools\GENERAL\Intel\ProSet\Ws03_32e\InstPROSet.EXE
For Windows Server 2003
[CD-ROM drive]:\Tools\GENERAL\Intel\ProSet\Ws03xp2k\InstPROSet.EXE
2 Click [Next].
3 Click [Accept].
4 Select [complete] for [Setup type] and click [Next].
5 Click [Install].
6 Click [Finish].
