Fujitsu Primergy TX120 - Where to Install the Memory Module; Installable Memory Modules and Notes

165
PRIMERGY TX120 User’s Guide
Installing hardware options
7
7.3.1 Where to Install the Memory Module
Install memory modules to the memory slots in the server.
• Memory slot 1A: For preinstalled memory module.
• Memory slot 2A, 1B, 2B: For add-on memory modules.
7.3.2 Installable Memory Modules and Notes
 Installable Memory Modules
The following memory module types can be used in this server.
 Order of Memory Module Installation
Install memory modules in ascending order of capacity, which are memory slot 1A, 1B, 2A and 2B.
table: List of Installable Memory Modules
Model Remarks
Memory Module-512MB (PG-RM51BE) 512MB (512MB-DIMM x 1)
Memory Module-1GB (PG-RM1BE) 1GB (1GB-DIMM x 1)
Memory Module-2GB (PG-RM2BE) 2GB (2GB-DIMM x 1)
Front Rear
㸣Baseboard
2A
1B
2B
1A
