174
Chapter 7 Installing Hardware Options
7.5.1 Where to Install Internal Hard Disk Units
Install internal hard disk units in 2.5-inch storage bay.
7.5.2 Installable Internal Hard Disk Units and Notes
Before installing an internal hard disk unit, check the following points.
 Installable Internal Hard Disk Units and Installation Order
The following types of SAS hard disks can be installed in this server. The internal hard disk unit should
be installed in descending order of the capacity.
Note that the hard disks with same capacity (same model) should be installed in the bay 1 and bay2
when configuring the array system.
table: Installable Internal Hard Disk Units
Product name Model number Overview
HDD SAS 10k 36GB hot plug 2.5inch
PG-HDD61A
36 GB, 10,000 rpm, SAS
2.5 inch, hot-pluggable
HDD SAS 10k 73GB hot plug 2.5inch
PG-HDD71A
73 GB, 10,000 rpm, SAS
2.5 inch, hot-pluggable
2.5-inch internal hard disk unit bay 2
2.5-inch internal hard disk unit bay 1
