PRIMERGY TX120 User’s Guide
Appendix
D.4 Remote Management Ctrl Upgrade kit (PG-RMCU1)
This option is a license key to make Remote Management Controller's console redirection function and
remote storage function effective.
z Console Redirection Function
The server can be remotely operated by using console redirection function. Remote operation such as the
keyboard and mouse operation, and seeing the contents of the display of the server are possible.
By using console redirection function, it makes possible to achieve the function of the KVM switching
in the environment where multiple servers are used. The composition of the multiple servers’
environment is shown in the figure below.
z Remote Storage Function
This is a function to recognize the external memory device connected by using the console redirection
function as a remote device of the server.
The configuration of the remote storage function is shown in the figure below.
table: Specifications of Remote Management Controller Upgrade
Item Specifications
Product Name Remote Management Ctrl Upgrade kit
Model PG-RMCU1
Function Console redirection function / Remote storage function
㪧㪩㪠㪤㪜㪩㪞㪰
㪟㪬㪙
㪚㪩㪫㪆㪢㪙㩷㫀㫅㫋㪼㫉㪽㪸㪺㪼
㪣㪘㪥
㪚㫆㫅㫊㫆㫃㪼
㪚㫆㫅㫊㫆㫃㪼
㪈
㪉
㪊
㪋
㪉
㪚㫆㫅㫊㫆㫃㪼㩷㫎㫀㫅㪻㫆㫎
㪊
㪈
㪧㪞㪄㪩㪤㪚㪬㪈
㪧㪞㪄㪩㪤㪚㪬㪈
㪧㪞㪄㪩㪤㪚㪬㪈
㪧㪞㪄㪩㪤㪚㪬㪈
㪧㪞㪄㪩㪤㪚㪬㪈
㪧㪞㪄㪩㪤㪚㪬㪈
㪚㫆㫅㫊㫆㫃㪼㩷㫎㫀㫅㪻㫆㫎
㪋
㪚㫆㫅㫊㫆㫃㪼㩷㫎㫀㫅㪻㫆㫎
㪚㫆㫅㫊㫆㫃㪼㩷㫎㫀㫅㪻㫆㫎
PRIMERGY
HUB
LANLAN
Console PC
Accessing as the remote drive
CD-ROM drive
Floppy disk drive
To Next Page
