PRIMERGY TX120 User’s Guide
1
Overview
1.3.3 Server (Internal)
a 2.5-inch storage bay
Contains an internal hard disk unit.
b Optional bay
Contains an internal bay option.
c Power supply unit
d Expansion Card Slot
Contains extension cards that enhance the server functions.
e Memory slot
Contains memory.
f CPU
a b c
f
de
Front Rear
