PRIMERGY TX120 User’s Guide
8
Configuring Hardware and utilities
8.2.7 PCI Configuration Submenu
Use this submenu to set the PCI device.
LAN Remote Boot
• Disabled (Initial value)
•PXE
Sets whether or not to perform a network boot.
This function allows booting the server via the
network.
You can set this item only when [LAN Controller]
is set to [Enabled].
Management LAN Enabled (Unchangeable) Sets whether to enable or disable the port for the
Remote Management Controller.
Hard Disk Controller Enabled (Unchangeable)
Sets whether to enable or disable the onboard SAS
controller.
Hard Disk Option ROM
Scan
Enabled (Unchangeable)
Sets whether or not to initialize the extended ROM.
table: Items on the PCI Configuration Submenu
Item Setting Description
PCI SLOTS Configuration Configures the PCI slots. Press the [Enter] key to display the [PCI SLOTS
Configuration] submenu window.
PCI 32 Slot 1 Configuration
Option ROM SCAN
• Enabled
• Disabled (Initial value)
Sets whether or not to initialize the extended
ROM in each PCI slot.
PCI-E (x8) Slot 2 Configuration
Option ROM SCAN
• Enabled
• Disabled (Initial value)
PCI-E (x1) Slot 3 Configuration
Option ROM SCAN
• Enabled
• Disabled (Initial value)
PCI IRQ Configuration Sets PCI IRQs for the PCI slots. Press the [Enter] key to display the [PCI
IRQ Configuration] submenu window.
PCI IRQ Line 1–8 Auto (Unchangeable) Sets the PCI IRQ.
table: Items on the Peripheral Configuration Submenu
Item Setting Description
Item Specific Help
Change Values-/+
F10
Select Item
Select Menu
Select Sub-MenuEnter
F1
Esc
Help
Exit
F9
Setup Defaults
Save and Exit
Advanced Security Server ExitMain
PCI Configuration
PCI SLOTS Configuration:
PCI IRQ Configuration:
