145
PRIMERGY TX120 User’s Guide
5
Operations after OS Installation
For Windows Server 2003
` If the OS is installed using ServerStart, "BACS" is already installed with the driver. If the OS is installed
manually, BACS will not be installed.
1 Execute the following file contained in the ServerStart Disc 1 CD-ROM.
[CD-ROM drive]: \PROGRAMS\GENERAL\Broadcom\MgmtApps\setup.exe
The installer starts up.
2 Proceed the installation by following the window instructions.
When the window below appears during the installation procedure, check [BASP] and click
[Next].
5.6.2 VLAN Setup Procedure
1 Click [Start] → [Control Panel] → [Broadcom Control Suite 2] to start up BACS.
2 Right-click a LAN adapter or the Team name of a teamed up adapter and click
[Create a VLAN] or [Add VLAN] from the displayed menu.
` A LAN adapter is displayed with a mark.
` The Team name of a Teamed Up adapter is displayed with a mark.
To Next Page
