171
PRIMERGY TX120 User’s Guide
Installing hardware options
7
Notes on Installing Expansion Cards
Install installable expansion cards only.
Before installing an expansion card, refer to the manual supplied with the expansion card.
7.4.3 How to Install Expansion Cards
1 Turn off the server and connected devices, and unplug all power cables from
the outlet.
2 Remove the side cover.
J"7.2 Removing and Attaching the Side Cover" (pg.162)
3 Touch a metal part of the server to discharge static electricity.
4 Push the tabs on the slot fixing cover (1) to open to the rear side (2), and
remove the slot cover (3).
` Be sure to keep the removed slot cover for later use.
If operating the server with no expansion card, attach the slot cover to keep dust away.
PUSH PUSH
