10.4.3 Temperature
The temperature-sensor is only fitted in devices of the WI series. It is located on the main
board. Its measurement range is from -55 to +125 °C with an accuracy of less than 1 °C.
In the Local Services -> Surveillance -> Temperature menu, a list of all triggers gener-
ated is shown. By default, lower and upper limits are set for the temperature; overstepping
these sets an alert variable and generates a syslog message. The values are updated
every 10 seconds.
10.4.3.1 New
Click on the New button to configure new limits.
Fig. 90: Local Services -> Surveillance-> Temperature -> New
The Local Services -> Surveillance ->Temperature -> New menu consists of the follow-
ing fields:
Fields in the Basic Parameters menu
Field Description
Trigger
Enter here the temperature limit value (min/max).
Possible values:
• /!" #3
• /!" #,
Action
Select the action that is to follow the state or state transition
defined in Trigger.
10 Local Services Funkwerk Enterprise Communications GmbH
176 funkwerk W1002/W2002/WIx040/WIx065
