Fig. 105: External Reporting -> SNMP-> SNMP Trap Hosts -> New
The External Reporting -> SNMP -> SNMP Trap Hosts-> New menu consists of the fol-
lowing fields:
Fields in the Basic Parameters menu
Field Description
IP Address Enter the IP address of the SNMP trap host.
12.4 Activity Monitor
This menu contains the settings needed to monitor your device with the Windows tool
Activity Monitor (part of BRICKware for Windows , which you can find in the download
area at www.funkwerk-ec.com).
Purpose
The Activity Monitor enables Windows users to monitor the activities of your device. Im-
portant information about the status of physical interfaces (e.g. ISDN line) and virtual inter-
faces is easily obtained with one tool. A permanent overview of the utilisation of your
device is possible.
Method of operation
A Status Daemon collects information about your device and transfers it as UDP packets to
the broadcast address of the first LAN interface (default setting) or to an explicitly entered
IP address. One packet is sent per time interval, which can be adjusted individually to val-
ues from 1 - 60 seconds. Up to 100 physical and virtual interfaces can be monitored,
Funkwerk Enterprise Communications GmbH
12 External Reporting
funkwerk W1002/W2002/WIx040/WIx065 197
