Field Description
SNR Shows the signal quality in dB.
Connected Displays the status of the link on your client.
Action You can change the status of the client link. The available ac-
tions are displayed in this field.
8.1.5 Bridge Links
If you operate your device in bridge mode (Wireless LAN -> WLANx -> Wireless Module
Settings -> -> Operating Mode = ($), you can set up and edit the desired bridge
links in the Wireless LAN -> WLANx -> Bridge Links -> ->/New menu.
With the bridge function, you can, for example, make a wireless connection between a
funkwerk Wx002 and one or more other funkwerk Wx002 devices. The range of these
wireless connections can be several kilometres, depending on the antennas used.
Note
Always use the antennas and antenna cables supplied with the equipment to prevent
unintentional violations of the applicable law. If you have special requirements, e.g. re-
garding cable lengths, please contact your dealer or an die Funkwerk Enterprise Com-
munications GmbH.
The use of this technology is free of charge in the Federal Republic of Germany. If a radio
path runs outside the boundary of your property, you only need to notify the Regulatory Au-
thority for Post and Telecommunications of the existence of the radio path. You will find the
regulatory authority on the Internet at www.regtp.de. The registration form can be found as
a PDF on our website www.funkwerk-ec.com.
Bridges are generally used to interconnect various LAN segments at Layer 2 of the OSI
7-layer model. The special feature of funkwerk bridges is that the distances between these
segments can be several kilometers, without the necessity of a cable for these ranges.
If you operate a wireless port in Bridge mode, this can only be used for a bridge link. This
means:
• The port has no network name.
• Wireless clients cannot log in (associate) to this port.
• There is no node table for this port (as there are no clients).
• There is no Access Control List (ACL) for this port.
This port will only connect to the partner bridge port you have configured and also only ac-
