3.2.2 General Product Features
To ensure safe operation, the WI series devices have a connection to earth. The minimum
cross-section of the earth lead should be 1.5 mm². The distance between the device and
the connection to earth should be as short as possible. For the funkwerk WIx065 devices,
the connection to earth is under the cover.
Fig. 21: Connection to earth funkwerk Wx040
The general product features cover performance features and the technical prerequisites
for installation and operation of your device.
The features are summarised in the following table:
General Product Features
Property Value
Variants:
funkwerk WI1040
funkwerk WI2040
funkwerk WI3040
One internal radio module, 2 external antennas (1x Main, 1x
AUX)
Two internal radio modules, 4 external antennas (2x Main, 2x
AUX)
Three internal radio modules, 4 external antennas (3x Main, 1x
AUX)
Dimensions and
weights:
Equipment dimensions
without cable (W x L x
H):
220 mm x 185 mm x 42 mm without feet
Weight approx. 1200 g (3 WLAN modules)
LEDs 8 (1x Failure, 1x Status, 3x WLAN, 2x Ethernet, 1x SFP)
3 Technical Data Funkwerk Enterprise Communications GmbH
34 funkwerk W1002/W2002/WIx040/WIx065
