Page #43 background imageLoading...
Page #43 background image
Property Value
Power consumption of
the device
5-15 Watt, depending on extensions
Voltage supply Earth conductor/connection to earth M4. All devices must be
earthed.
24V DC 1,1A ± 30 % with reverse voltage protection, insulated
3-pole
PoE on Ethernet 1 Class 0 (insulated) with max. two WLAN
modules
Protection against theft Theft protection is available as an option
Temperature sensor Temperature monitoring and software-controlled actions pos-
sible
Environmental require-
ments:
Storage temperature -25 °C to +85 °C
Operating temperature -25 °C to +70 °C
Relative atmospheric hu-
midity
10 % to 95 % (non-condensing)
Room classification Operate only in dry rooms
Available interfaces:
Serial interface V.24 Permanently installed, supports Baud rates: 1200, 2400, 4800,
9600, 19200, 38400, 57600, 115200 Baud
Ethernet IEEE 802.3
LAN
Permanently installed (twisted pair only), 10/100 mbps, auto-
sensing, MDI/MDIX 2x 10/100 Base T/TX
MMC/SD card slot Save and load of configuration via MMC/SD card possible
(optional, in preparation)
Relay An alarm using relay is possible in the event of overtemperature
or error: potential-free working contact, 1A 125V AC / 2A 30 V
DC
Optical interface Module slot for optical interface 100 mbps LWL Single Mode LC
or LWL Multimode LC - 1x 100 Base FX/SX with SFP module
Funkwerk Enterprise Communications GmbH
3 Technical Data
funkwerk W1002/W2002/WIx040/WIx065 35
