Funkwerk W1002 - Installation; Setting Up and Connecting Devices

Fig. 5: Basic Scenario - Mobility /WIx065)
Caution
Please read the safety precautions carefully before installing and starting up your
device. These are supplied with the device.
2.4.1 Connections
All connections are located on the bottom of the device.
The only connections on the top of the device are those for screwing on the external stand-
ard antennas. On the funkwerk W2002, there are two connections for the external stand-
ard antennas on the top, and two on the bottom.
2 Quick Install Guide Funkwerk Enterprise Communications GmbH
10 funkwerk W1002/W2002/WIx040/WIx065
