Field Description
quest packets.
Interval
Shows the interval is seconds during which the ping is to be
sent to the destination IP address.
State Shows the operating state of the destination IP address.
10.4.4.1 Edit / New
Choose the icon to edit existing entries. Choose the New button to set up further pings.
Fig. 92: Local Services -> Surveillance-> Ping Generator -> New
The Local Services -> Surveillance ->Ping Generator -> New menu consists of the fol-
lowing fields:
Fields in the Basic Parameters menu
Field Description
Destination IP Address Enter the IP address to which the ping is automatically sent.
Source IP Address Enter the source IP address of the outgoing ICMP echo request
packets.
Possible values:
• "": The IP address is determined automatically.
• ! (default value): Enter the IP address in the adja-
cent input field e.g. to test a particular extended route.
10 Local Services Funkwerk Enterprise Communications GmbH
178 funkwerk W1002/W2002/WIx040/WIx065
