Fig. 113: Monitoring -> WLAN -> WDS
Values in the list WDS
Field Description
WDS Description Displays the name of the WDS link.
Remote MAC Displays the MAC address of the WDS link partner.
Uptime Shows the time in hours, minutes and seconds for which the
WDS link is active.
Tx Packets Displays the total number of packets sent.
Rx Packets Displays the total number of packets received.
Signal dBm Shows the received signal strength in dBm.
Noise dBm Shows the received noise strength in dBm.
Data Rate Mbps
Shows the current transmission rate of data received on this
WDS link in Mbps.
If required, the Test link can be used to start a link test.
The link test provides all the data necessary for checking the quality of the WDS link. The
link test also helps you to align the antennas. This option is only displayed if the link state is
7#,.
WDS Link Details
You use the icon to open an overview of further details for the WDS links.
Funkwerk Enterprise Communications GmbH
13 Monitoring
funkwerk W1002/W2002/WIx040/WIx065 207
