General Product Features
Property Value
Variants:
funkwerk W1002
funkwerk W2002
One internal radio module, 2 external antennas
Two internal radio modules, 4 external antennas
Dimensions and
weights:
Equipment dimensions
without cable (W x L x
H):
161 mm x 168 mm x 50 mm
Weight approx. 200 g
LEDs 5 (1x Status, 2x WLAN, 2x Ethernet)
Power consumption of
the device
5-10 Watt, depending on extensions
Voltage supply External transformer mains unit 12 V DC, 1 A
Environmental require-
ments:
Storage temperature -10° to +70 °C
Operating temperature 0° to 40 °C
Relative atmospheric hu-
midity
10 % to 95 % (non-condensing)
Room classification Only use in dry rooms.
Available interfaces:
Serial interface V.24 Permanently installed, supports Baud rates: 1200, 2400, 4800,
9600, 19200, 38400, 57600, 115200 Baud
Ethernet IEEE 802.3
LAN (4-port switch)
Permanently installed (twisted pair only), 10/100 mbps, auto-
sensing, MDIX
Funkwerk Enterprise Communications GmbH
3 Technical Data
funkwerk W1002/W2002/WIx040/WIx065 27
