Property Value
Relative atmospheric hu-
midity
10 % to 100 % (non-condensing)
Available interfaces:
Serial interface V.24 Permanently installed, supports Baud rates: 1200, 2400, 4800,
9600, 19200, 38400, 57600, 115200 Baud
Ethernet IEEE 802.3
LAN
Permanently installed (twisted pair only), 10/100 mbps, auto-
sensing, MDI/MDIX 2x 10/100 Base T/TX
MMC/SD card slot Save and load of configuration via MMC/SD card possible
(optional, in preparation)
Relay An alarm using relay is possible in the event of overtemperature
or error: potential-free working contact, 1A 125V AC / 2A 30 V
DC
Optical interface Module slot for optical interface 100 mbps LWL Single Mode LC
or LWL Multimode LC - 1x 100 Base FX/SX with SFP module
Available sockets:
Serial interface V.24 9-pin serial Sub-D port
MMC/SD card slot With protective cover if card is inserted.
Relay switching contact
N/O
30V AC/DC 0.5 A potential-free, software configurable, switch-
able
Ethernet interface RJ45 socket
Antennas:
Antenna connection RTNC socket
Transmit Power (WLAN) max. 100 mW (20 dBm) EIRP
Receiver sensitivity In the 5 GHz frequency range
PER 10 %
6 mbps -90 dBm, 9 mbps -88 dBm,
12 mbps -86 dBm, 18 mbps -84 dBm,
24 mbps -79 dBm, 36 mbps -76 dBm,
48 mbps -71 dBm, 54 mbps -69 dBm
3 Technical Data Funkwerk Enterprise Communications GmbH
44 funkwerk W1002/W2002/WIx040/WIx065
