Button Function
configuring the certificates or CRL imports.
In the VPN -> Certificates -> Certificates menu, this button
opens the sub-menu for the configuration of the certificate re-
quest.
In the Surveillance -> ISDN/Modem -> Current Calls menu,
clicking on this button ends the active calls selected in the
column .
Various icons indicate the following possible actions or statuses:
Funkwerk Configuration Interface icons
Visual aids Function
Deletes the list entry.
Displays the menu for changing the settings of an entry.
Displays the details for an entry.
Moves an entry. A combo box opens in which you can choose
the list entry that selected entry is to be be placed in front of/
after.
Creates another list entry first and opens the configuration
menu.
Sets the status of the entry to 2"3 .
Sets the status of the entry to "3.
Indicates "Dormant" status for an interface or connection.
Indicates "Up" status for an interface or connection.
Indicates "Down" status for an interface or connection.
Indicates "Blocked" status for an interface or connection.
Indicates "Going up" status for an interface or connection.
Indicates that data traffic is encrypted.
Triggers a WLAN bandscan.
Displays the next page in a list.
Displays the previous page in a list.
Funkwerk Enterprise Communications GmbH
4 Access and Configuration
funkwerk W1002/W2002/WIx040/WIx065 63
