Revision 14
128 August 02, 2019
5.18.1 Schedule
The Schedule for each timer consists of the Day field where any specific day or “every day”
can be selected from the pull down menu and the Hour and Minute fields. The time fields
operate on 24 hour military time (e.g. 3:00AM=0300, 3:00PM=15:00).
Basically the analyzer cannot execute any timed gas runs scheduled from
12:00 AM to 12:59AM. in this mode Normally the time 00:15 would signifiy
15 minutes past midnight but for this application putting a zero in the hour
field would tell the analyzer to do whatever is scheduled in that column to
run every hour.
5.18.2 Analysis
The Enable checkbox must be checked before any of the gas runs listed below can be
executed on a timer. For any of the analysis types, the schedule time would be used to
initiate a single operation which may consist of one run or as many runs indicated in the
Consecutive check box located for that run type on the Streams tab.
5.18.3 Sequences
The operations in this section are Manual Sequences that can be set to run for any specific
time period up to a week. The manual sequencers require a Start time and a Stop time:
therefore the date and time on two timers need to be entered. The Start and Stop
checkboxes also need to be checked to enable this operation to execute.
