4.8 The Configuration Menu
When CFNG (F4) is pressed on the Main page, the display appears as shown in Figure 4-12.
The function keys lead to four menus that are described in Sections 4.8.1 through 4.8.4.
Figure 4-12: The Configuration Page
4.8.1 The Gen Menu
When GEN (F1) is selected on the Configuration page (Figure 4-13), the General menu is
presented (Figure 4-16).
Figure 4-13: The General Menu
• TAPE - indicates the tape length that remains. The value can be changed (e.g. when the
tape is replaced) by pressing the EDIT key on the keypad. A query will be presented and the
appropriate tape length should be entered, followed by the ENTER key.
• ACK_AL - This field is used to acknowledge all latched alarms. To acknowledge the latched
alarms, press the EDIT key and use the ENTER key to toggle the value to ON. Note that
any latched alarms will not unlatch if they are still in the alarm condition.
• L mV – This field is used to set the mV on the display to corrected mV (indicated by mV on
the display) or live uncorrected live mV (indicated by LmV on the display). This function
(On/OFF) can be edited by pressing the EDIT key followed by the ENTER key.
• L ppm - This field is used to set the concentration reading on the display to the last
calculated value (indicated by the absence of the L in front of the analysis units) or to the
current analysis live value (indicated by the presence of the L in front of the analysis units).
This function (On/OFF) can be edited by pressing the EDIT key followed by the ENTER key.
• DAY - presents the day of the week and cannot be edited.
• TIME - presents the present time and cannot be edited.
To Next Page
