Lock
Analysis Alarms – Zero
)
High Alarm
High High Alarm
Deviation
Lock
Analysis Alarms – Calibration
)
High Alarm
High High Alarm
Deviation
Lock
4.7 The Display Menu
When F3 is pressed on the main page, the Display menu appears as shown in Figure
4-7.The function keys lead to four menus that are described in Sections 4.7.1 through 4.7.4.
mV Run State Time
6 1H1 S1 115
10.0 ppm
F1 F2 F3 F4
SQNC IO READ SCHED
Figure 4-7: Display Menu
4.7.1 The SQNC Menu
A typical SQNC (Sequence) menu is presented in Figure 4-8. The sequence is entered via
the GUI (Section 5.14) and indicates the order of measurements that occur during a cycle.
The sequence cannot be edited via the hand held keypad.
mV Run State Time
6 1H1 S1 115
• AUTO
• S1: H2S
• S1: TS
• S1: REF1
F1 F4
PGUP PGDN
Figure 4-8: SQNC Menu
When F4 (PGDN) is pressed, additional lines in the sequence will be displayed.
