4.7.2 I/O Menu
A typical IO (Input/Output) menu is presented in Figure 4-9. The values that are presented
are the live values for the analog (AO) outputs, digital (DO) outputs and relays that have been
activated via the GUI and cannot be edited via the hand held keypad.
mV Run State Time
6 1H1 S1 115
Analyzer IO State:
AO_1 mA 4.06
AO_2 mA 4.09
AO_3 mA 4.11
F1 F2 F3 F4
PGUP PGDN
Figure 4-9: The IO Menu
4.7.3 Analyzer Reading Menu
A typical Analyzer Reading menu is presented in Figure 4-10. The values that are presented
are the most recent value for the various reading for each analysis (e.g. S1:H2S 10.0
means that the last reading for H
2
S was 10 ppm) and cannot be edited.
mV Run State
Time
6 1H1 S1 115
Analyzer Reading:
S1:H2S 10.0
S1:TS 4.0
S1:REF1 6.7
S1:REF2 8.9
F1 F2 F3 F4
PGUP PGDN
Figure 4-10: Analyzer Reading Menu
4.7.4 Analyzer Schedule Menu
The Analyzer Schedule menu (Figure 4-11) shows what stream is currently being analyzed
and what streams (if any) are pending.
mV Run State Time
6 1H1 S1 115
Analyzer Schedule:
S1:H2S ON
S1:TS PENDING
F1 F2 F3 F4
PGUP PGDN
Figure 4-11: Analyzer Scheduler Menu
