6.8 Monitoring System Operation
The Events tab (Figure 6-16) presents a log of all operations that occur during operation and
is a useful way to monitor the system. It tracks all alarm conditions experienced by the
analyzer, both global and stream related, but also such things as changes in configuration
and power up events. A detailed discussion of the Events tab is presented in Section 5.8.
Figure 6-16: The Events Tab
The Alarms tab (Figure 6-17) allows the operator to view the status of most of the enabled
analyzer alarms. A detailed discussion of the Alarms tab is presented in Section 5.6.
