Galvanic Applied Sciences ProTech903 - Table 4-4: Function Keyd

Revision 14
60 August 02, 2019
Table 4-4: Function Key Definitions
Key
Function
F1
On the Main page (Figure 4-2), the F1 key accesses the Stream (STRM) menu
(Section 4.5) and is used to select the stream of interest.
On other screens, the F1 key is used as a page-up (PGUP) function key to scroll
through multiple menu screens if required or is used to select a sub-menu.
F2
On the Main page (Figure 4-2), the F2 key accesses the Analyzer Alarm (ALRM)
list. (Section 4.6).
On other screens, the F2 key is used as an up (UP) function key to scroll through
multiple menu screens if required or is used to select a sub-menu.
F3
On the Main page, the F3 key accesses the Display (DISP) settings (Section 4.7).
On other screens, the F3 key is used as a down (DN) function key to scroll
through multiple menu screens if required or is used to select a sub-menu.
F4
On the Main page (Figure 4-2), the F4 key accesses the Configuration (CNFG)
menu.
On other screens, the F4 key is used as a page down (PGDN) function key to
scroll through multiple menu screens if required or is used to select a sub-menu.
BYPASS
Pressing this key will put the analyzer into Bypass mode. Pressing this key again
will exit Bypass mode.
TAPE
ADVANCE
Pressing this key will cause the analyzer to cease the current analysis, advance
the tape, and begin a new cycle.
EDIT
Pressing this key on editable items will allow the user to enter in a new value of
setting (e.g. ON/OFF) for the active menu item.
EXIT
Exits any other menu screen and returns to the main display screen Figure 4-2).
ENTER
While editing any editable menu item, pressing ENTER will cause the analyzer to
accept the newly entered value.
When a menu is presented, the top two lines will always present the system status, the next
four lines will present the relevant settings (information) and the bottom two lines will present
the soft key definitions. A typical menu (from the STRM menu) is shown in Figure 4-4, There
are four lines which present information on a page, if the menu contains more than four lines
of information, the additional items can be accessed by pressing the PGUP, UP, DN and
PGDN keys (F1-F4).
mV Run State Time
6 1H1 S1 115
H2S-H 16.00 OFF
H2S-HH 18.00 OFF
H2S-DU 0.00 OFF
H2S-LC 4.00 OFF
F1 F2 F3 F4
PGUP UP DOWN PGDN
Figure 4-4: The Streams Menu
