Consecutive Runs. It will then average the number of results together as defined by Runs
to Average. A new Gain Factor will be automatically calculated using the calibration gas
value defined in Cal.Gas Concentration.
c) When the Auto Calibration is complete the analyzer will automatically return to the
previously defined automatic sequence.
6.7 Analyzing Samples
The operation of the system is governed by the data on the Sequencer or Timers tab and the
analyzer can be operated on a manual or automated basis. The Analysis tab (Figure 6-13) is
a live presentation of the analytical data and allows the operator to see the status of many
facets of the analyzer all at a glance. The application program polls the analyzer every 3
seconds, causing this page to be updated continuously. A detailed discussion of the Analysis
tab is presented in Section 5.4.
Figure 6-13: The Analysis Tab
All data is stored in the computer that is onboard the analyzer and can be retrieved as
desired using the Archive tab (Figure 6-14). A detailed discussion of the Archive tab is
presented in Section 5.7.
