4.8.3 The AIO Menu (Analog Inputs/Outputs)
When AIO (F3) is pressed on the Configuration page (Figure 4-12), the AIO display which
describes the analog outputs appears as shown in Figure 4-15. The central column is the
analog input or output full scale, which can be edited, by pressing the EDIT button, entering
the desired value and pressing ENTER and the right column is the present reading
mV Run State Time
6 1H1 S1 115
A1_1 50.00F -12.38
Al-2 50.00 -12.39
Al_3 50.00 -12.44
Al_4 50.00 60.74
F1 F2 F3 F4
PGUP Up Down PGDN
Figure 4-15: The AIO Display
4.8.4 The MSEQ Menu (Manual Sequencer)
When MSEQ (F4) is selected on the Configuration menu (Figure 4-12), the MSEQ menu is
presented. A typical menu is shown in Figure 4-16. This menu allows the user to initiate
manual sequences (for additional information, see Section 5.14.3).
mV Run State Time
6 1H1 S1 115
SEQNC OFF
Manual OFF
SEQ 1 OFF
SEQ 2 OFF
F1 F2 F3 F4
PGUP Up Down PGDN
Figure 4-16: The MSEQ Menu
