GE Security EST3 User Manual

Installation
EST3 Installation and Service Manual 5.13
+ −
+ −
+ − + −
S H
Temporal horn/strobe
and G1M module
47 k
EOLR
Ω
Temp ora l
horn/strobe
+ −
AUX riser from
previous device
12345678
910
78
1234
6
+ −
Normal
+ −
Active
Data in ( )
+
Data in ( )
−
From
previous device
Data out ( )
+
Data out ( )
−
To
next device
+ −
AUX riser to next
device or riser monitor
Relay module Model: CR Device type: Dry contact Personality: (8) Dry contact Label: Zone_1_NAC_Silence
Single Input Signal module
Model: CC1 Device type: Visible Personality: (5) Riser selector Label: Zone_1_NAC
Figure 5-4: Typical SIGA-CC1 NAC wiring
