Security applications
2.2 EST3 Installation and Service Manual
Security equipment
Introduction
The equipment required for a general security system is shown in
Figure 2-1. We’ll discuss each item shown in the drawing, plus
the other factors called out on the drawing.
Central
monitoring
station
Telephone lines
Control panel
Signature Controller
Module
Power supply
Other factors
Hardware configuration
SDU programming
ACDB/KDC operation
X
X
X
X
SAC bus
Signature data circuit
KDC program
SEC2
Security Loop
Module
3-SAC
Security Access Control
Module
3-MODCOM
Modem Communication
Module
MD
Motion Detector
Signature fire
alarm
devices
KPDISP
Keypad Display
Conventional
security devices
Distributor
SDU
RPM
Resource
profile
Figure 2-1: Equipment required for a basic security system
Equipment
The equipment used in security applications includes:
• Control panel
• Signature Controller module
• SIGA-MD Motion Detector module
• SIGA-SEC2 Security Loop module
• 3-SAC Security Access module
• SAC bus
