Installation
EST3 Installation and Service Manual
5.54
1
8
3
2
6
7
5
1
2
3
4
5
6
7
8
MFCA/Modem Installation
SIGA-MP1 mounting plate
Slotted pan head screw, #6-32X3/8
Lock washer, #6
MFCA Enclosure
Quick opening screw #362219
Conduit knockout
Tamper switch mounting screws
Cable ties
Modem
Figure 5-12: Suggested modem installation using MFCA and
SIGA-MP1
